A Comparison of Welch Ultisil Columns on the Isomeric Separation of Anthraquinones

Table of contents

Introduction The Separation of Anthraquinones Chromatographic Conditions and Column Selection Chromatogram and Data Ultisil PFP Ultisil Alk-C18 Ultisil XS-C18 Conclusion

Introduction

Isomer separation is one of the most challenging tasks in chromatography. Due to the similarities in structure, isomers often possess nearly identical partition coefficients, resulting in co-elution or insufficient resolution under standard chromatographic conditions. This difficulty is particularly pronounced when dealing with positional isomers, such as meta- and para-substituted benzene derivatives, where the subtle differences in molecular geometry provide minimal handles for separation.

In routine analytical practice, overcoming these challenges typically requires the selection of stationary phases that offer superior shape selectivity or specific spatial interaction capabilities.

The Separation of Anthraquinones

Anthraquinones represent a significant class of organic molecules, with extensive utility in both the synthetic dye industry and the characterization of various natural products. However, the precise separation and quantification of isomeric anthraquinone derivatives (e.g., 1,5-dinitroanthraquinone and 1,8-dinitroanthraquinone) along with other analogs (e.g., nitroanthraquinone and anthraquinone itself) remain a persistent challenge in quality control and research.

In the following application, we employ three of Welch Materials' Ultisil columns (PFP, Alk-C18, and XS-C18) and compare their performances in the separation of anthraquinones to determine the optimal stationary phase for enhancing resolution and analytical efficiency.

Chromatographic Conditions and Column Selection

Chromatographic conditions:

Mobile phase: ACN/THF/H2O = 45/10/45
Flow rate: 1.0 mL/min
Injection volume: 10 µL
Column temperature: 30 °C
Detector wavelength: 254 nm

Column choice:

All the three columns used are 4.6×250 mm, 5 µm. This eliminates the influence to resolution caused by column specifications.

Chromatogram and Data

Ultisil PFP

Ret. Time	Peak Area	Height	Area %	Res.	Plates	Asym.
8.12	80.81	532.05	13.14	n.a	18183	0.97
9.02	305.00	1779.57	49.60	n.a	n.a	n.a
9.21	229.11	1630.87	37.26	n.a	n.a	n.a

Only three peaks are eluted, and complete baseline separation is not achieved.

Ultisil Alk-C18

Ret. Time	Peak Area	Height	Area %	Res.	Plates	Asym.
6.89	81.77	493.81	13.31	1.57	12431	n.a
7.29	110.46	641.51	17.98	3.06	12254	n.a
8.10	176.04	1008.21	28.66	5.29	14608	1.06
9.61	245.96	1223.35	40.04	n.a	15729	1.07

All four compounds are separated, but the resolution between the isomer peaks is not satisfactory.

Ultisil XS-C18

Ret. Time	Peak Area	Height	Area %	Res.	Plates	Asym.
6.38	80.36	645.23	13.04	2.92	16838	0.98
6.98	112.03	851.66	18.17	5.37	16472	0.98
8.15	178.78	1289.44	29.00	13.89	22071	1.04
11.73	245.26	1309.17	39.79	n.a	25008	1.06

Optimal separation of anthraquinones: symmetrical peaks, high resolution, no overlap between peaks, and all target compounds can be clearly differentiated.
Demonstrates exceptional steric and conformational selectivity.
Offers more stable and efficient separation compared to the other two columns.

Conclusion

Compared to Ultisil PFP and Ultisil Alk-C18, Ultisil XS-C18 shows an optimal performance in the separation of anthraquinone derivatives. Its unique multi-layer bonding technology provides high bonding density, excellent steric selectivity, and close inter-ligand spacing, enabling it to effectively distinguish between isomers. Therefore, it is particularly well-suited for the separation and purification of small-molecule structural isomers, demonstrating unique separation advantages among counterpart C18 columns.
