Determination of Mannitol Related Substances with Xtimate Sugar-Ca

Determination of Mannitol Related Substances with Xtimate Sugar-Ca

Introduction

Mannitol is a six-carbon sugar alcohol with important applications in pharmaceutical and food industries.

In pharmaceutical industry, it is used as a hyperosmotic diuretic. It increases plasma osmotic pressure upon intravenous administration, promoting the transfer of interstitial fluid into the vascular system. This reduces tissue edema and lowers intracranial pressure, demonstrating remarkable efficacy for conditions such as cerebral edema and renal edema while also preventing acute renal failure. Its diuretic effect aids in eliminating excess water and electrolytes from the body. However, strict control of dosage and infusion rate is essential to avoid adverse reactions like electrolyte imbalance and osmotic nephropathy.

In food industry, it serves as a sweetener and humectant, widely used in the production of candies, chewing gum, baked goods, and other food products. It possesses moisture-retaining properties and prevents crystallization.

Structure formula of mannitol

National Standards for Mannitol Determination

Due to the importance of mannitol in these industries, its determination is monographed in major pharmacopoeias worldwide, notably USP-NF 2025, EP 11, JP 18, and ChP 2025.

For example, in Chinese Pharmacopoeia 2025 Edition, the related substance section specifies that the retention times of isomalt peak 1, maltitol, isomalt peak 2, and sorbitol relative to mannitol should be 0.60, 0.69, 0.73, and 1.2, respectively; the resolution between mannitol and sorbitol peaks should be greater than 2.0 in system suitability solution I, and the resolution between maltitol and isomalt peak 1 should satisfy in system suitability solution II. Sample preparation protocols in this edition are also modified to better align with other pharmacopoeias mentioned above, enhancing the accuracy of the standard.

Application Example using Welch Xtimate Sugar-Ca Column

Chromatographic conditions:

  • Column: Xtimate Sugar-Ca (7.8×300 mm, 5 µm)
  • Method Source: ChP 2025
  • Mobile Phase: Water
  • Flow Rate: 0.5 mL/min
  • Injection Volume: 20 µL
  • Column Temperature: 80 °C
  • Detector: RID, 40 °C
Chromatogram of mannitol blank solution
Blank solution
Chromatogram of mannitol system suitability solution I
System Suitability Solution I
# Ret. Time Area Height Sym. Width Plates Res. Select.
1 20.138 8801740 350852 0.85 0.386 15054

2 24.665 8631980 280760 0.81 0.475 14937 6.18 1.22
Chromatogram of mannitol system suitability solution II
System Suitability Solution II
# Ret. Time Area Height Sym. Width Plates Res. Select.
1 13.039 169516 7477 0.93 0.353 7568

2 14.161 367573 14881 0.93 0.391 7266 1.77 1.09
3 14.745 184378 7107 0.81 0.458 5743 0.81 1.04
Chromatogram of mannitol system suitability solution III
System Suitability Solution III
# Ret. Time Area Height Sym. Width Plates
1 20.098 11344.6 448.472 0.99 0.386 15042
Chromatogram of mannitol reference solution
Reference Solution
# Ret. Time Area Height Sym. Width Plates
1 20.198 335100 13524 0.98 0.382 15518
Chromatogram of mannitol test solution
Test Solution
# Ret. Time Area Height Sym. Width Plates
1 20.072 16982000 662609 0.77 0.398 14103
Analyte RRT in ChP RRT analyzed
Isomalt peak 1 0.60 0.65
Maltitol 0.69 0.70
Isomalt peak 2 0.73 0.73
Mannitol 1.0 1.0
Sorbitol 1.2 1.2

Conclusion

Using Welch Xtimate Sugar-Ca (7.8×300 mm, 5 µm) column under the conditions specified in Chinese Pharmacopoeia 2025 Edition,

  • In system suitability solution I, the resolution between mannitol and sorbitol peaks reaches 6.18, greater than the required 2.0;
  • In system suitability solution II, the resolution between maltitol and isomalt peak 1 reaches 1.77, satisfying the requirement; furthermore, maltitol peak and isomalt peak 2 are not completely overlapped.

Therefore, the use of Xtimate Sugar-Ca (7.8×300 mm, 5 µm) fulfills the requirements in ChP 2025 for mannitol related substances analysis.
