P/N: 00410-02039

Topsil C18, 3μm, 4.6×100mm

Regular price $450.00 USD
Sale price $450.00 USD Regular price
Sale Sold out
Unit price
/per
This is a pre order item. We will ship it when it comes in stock.

Topsil C18 offers distinct selectivity compared to other C18 columns from Welch Materials. With lower column pressure and higher efficiency, it is an economical HPLC column choice.

Pairs well with

Topsil series HPLC column is a next-generation column by Welch, besides Ultisil, Xtimate and Welchrom. This series use different silica and provide different selectivity.

Features

  • High purity silica (99.99%) with 150 Å pore size and 260 m2/g surface area
  • 12% carbon loading for C18 phase
  • Because of large pore and moderate carbon loading, Topsil C18 phase can also be used as AQ-C18 without phase collapse
  • Endcapped for excellent peak shape and lifetime
  • Lower back pressure than Ultisil, almost the same column efficiency as Ultisil columns
  • Good for small molecules and peptides
  • Topsil phases including C18, C8, Phenyl-Hexyl, Silica, NH2, HILIC NH2 and CN

Brand: Topsil

Phase: Top-C18

Particle Size: 3μm

Pore Size: 150Å

USP Classification: L1

Separation Mode: Reversed Mode

pH Range: 2.0-8.0

Surface Area: 260m2/g

Carbon Load: 12%

Max.Pressure: 60Mpa

Endcapped: Yes

Max.Temp.: 60°C(pH≤6.5) and 40°C(pH>6.5)

Particle Shape: Spherical

Column Cross Reference:
(Please kindly note that columns among brands are never 100% the same. The below cross reference list indicates alternatives column(s) that will likely give a similar selectivity. Inevitable differences in retention time, resolution and theoretical plate count exist and may affect the results for certain circumstances.)

  • Agilent Pursuit C18
  • Agilent Polaris C18-A
  • Phenomenex Luna C18 (2)
  • Thermo BetaBasic C18
  • Waters Nova-Pak C18
Product Description

Topsil series HPLC column is a next-generation column by Welch, besides Ultisil, Xtimate and Welchrom. This series use different silica and provide different selectivity.

Features

  • High purity silica (99.99%) with 150 Å pore size and 260 m2/g surface area
  • 12% carbon loading for C18 phase
  • Because of large pore and moderate carbon loading, Topsil C18 phase can also be used as AQ-C18 without phase collapse
  • Endcapped for excellent peak shape and lifetime
  • Lower back pressure than Ultisil, almost the same column efficiency as Ultisil columns
  • Good for small molecules and peptides
  • Topsil phases including C18, C8, Phenyl-Hexyl, Silica, NH2, HILIC NH2 and CN

Specifications

Brand: Topsil

Phase: Top-C18

Particle Size: 3μm

Pore Size: 150Å

USP Classification: L1

Separation Mode: Reversed Mode

pH Range: 2.0-8.0

Surface Area: 260m2/g

Carbon Load: 12%

Max.Pressure: 60Mpa

Endcapped: Yes

Max.Temp.: 60°C(pH≤6.5) and 40°C(pH>6.5)

Particle Shape: Spherical

Column Cross Reference:
(Please kindly note that columns among brands are never 100% the same. The below cross reference list indicates alternatives column(s) that will likely give a similar selectivity. Inevitable differences in retention time, resolution and theoretical plate count exist and may affect the results for certain circumstances.)

  • Agilent Pursuit C18
  • Agilent Polaris C18-A
  • Phenomenex Luna C18 (2)
  • Thermo BetaBasic C18
  • Waters Nova-Pak C18
